S30 Tiltrotator Buckets

Paint specification:
Bucket:RAL 9017 Traffic Black (Gloss Finish)
logo: RAL 5012 Light Blue (Gloss Finish)

Share On Social Media

300 CABLE BUCKET

front
back

PARTS LIST

ITEM
DESCRIPTION
MATERIAL
THICKNESS
QTY
1
CUTTING EDGE
HB400
16
1
2
SIDE TOP PLATE
HB400
10
1
3
SIDE BOTTOM PLATE
ST52.3
6
1
4
ROLL SHEET
HB400
6
1
5
SIDE WEAR STRIP
HB400
5
2
6
TUBE
ST52.3
-
1
7
EAR PLATE
ST52.3
10
2
8
S30 PIN
EN8D
2
9
TOP PLATE
ST52.3
8
1
10
BOTTOM PLATE
ST52.3
8
1
11
BOTTOM WEAR STRIP
HB400
6
5
12
ACL LOGO
ST52.3
5
2
inside

NOTE:
STRUCK CAPACITY – 40 LITERS
HEAPED CAPACITY – 45 LITERS

Paint specification:
Bucket:RAL 9017 Traffic Black (Gloss Finish)
logo: RAL 5012 Light Blue (Gloss Finish)

diagram3
diagram2
diagram1

300 CABLE BUCKET

front
back

PARTS LIST

ITEM
DESCRIPTION
MATERIAL
THICKNESS
QTY
1
CUTTING EDGE
HB400
16
1
2
SIDE TOP PLATE
HB400
10
1
3
SIDE BOTTOM PLATE
ST52.3
6
1
4
ROLL SHEET
HB400
6
1
5
SIDE WEAR STRIP
HB400
5
2
6
TUBE
ST52.3
-
1
7
EAR PLATE
ST52.3
10
2
8
S30 PIN
EN8D
2
9
TOP PLATE
ST52.3
8
1
10
BOTTOM PLATE
ST52.3
8
1
11
BOTTOM WEAR STRIP
HB400
6
5
12
ACL LOGO
ST52.3
5
2
inside

NOTE:
STRUCK CAPACITY – 40 LITERS
HEAPED CAPACITY – 45 LITERS

Paint specification:
Bucket:RAL 9017 Traffic Black (Gloss Finish)
logo: RAL 5012 Light Blue (Gloss Finish)

diagram3
diagram2
diagram1

450 CABLE BUCKET

front
back

PARTS LIST

ITEM
DESCRIPTION
MATERIAL
THICKNESS
QTY
1
CUTTING EDGE
HB400
16
1
2
SIDE TOP PLATE
HB400
10
2
3
SIDE BOTTOM PLATE
HB400
6
2
4
ROLL SHEET
ST52.3
6
1
5
SIDE WEAR STRIP
HB400
5
2
6
TUBE
ST52.3
-
1
7
EAR PLATE
ST52.3
10
2
8
S30 PIN
EN8D
2
9
TOP PLATE
ST52.3
8
1
10
BOTTOM PLATE
ST52.3
8
1
11
BOTTOM WEAR STRIP
HB400
6
5
12
ACL LOGO
ST52.3
5
2
inside

NOTE:
STRUCK CAPACITY – 64 LITERS
HEAPED CAPACITY – 80 LITERS

Paint specification:
Bucket:RAL 9017 Traffic Black (Gloss Finish)
logo: RAL 5012 Light Blue (Gloss Finish)

diagram3
diagram2
diagram1

600 DIGGING BUCKET

front 1
back1
back2

NOTE:
STRUCK CAPACITY – 98 LITERS
HEAPED CAPACITY – 110 LITERS

Paint specification:
Bucket:RAL 9017 Traffic Black (Gloss Finish)
logo: RAL 5012 Light Blue (Gloss Finish)

PARTS LIST

ITEM
DESCRIPTION
MATERIAL
THICKNESS
QTY
1
CUTTING EDGE
HB400
150 x 20
1
2
ROLL SHEET
ST52.3
6mm
1
5
SIDE TOP PLATE RH
HB400
8mm
1
6
SIDE BOTTOM PLATE RH
HB400
5mm
1
7
TOP PLATE
ST52.3
6mm
1
8
BOTTOM PLATE
ST52.3
6mm
1
9
TUBE
ST52.3
Dia 60
1
10
WEAR PLATE 1
HB400
6mm
1
11
WEAR PLATE 2
HB400
6mm
3
12
TOP GUSSET PLATE
ST52.3
8mm
2
13
8J7525 ADAPTOR
Iron, Cast
STD
4
14
1U3202RC TOOTH
Iron, Cast
STD
4
15
ATTACHMENT LLC LOGO
ST52.3
5mm
2
16
SIDE GUSSET PLATE
ST52.3
6mm
2
17
SIDE BOTTOM PLATE LH
HB400
5mm
1
18
SIDE TOP PLATE LH
HB400
8mm
1
19
SIDE STIFFNER
HB400
6mm
2
20
S30 PIN
EN8D
-
2
21
EAR PLATE
ST52.3
10mm
2
front 2
diagram3
diagram2
diagram1

900 GRADING BUCKET

front 3
back 1
side

PARTS LIST

ITEM
DESCRIPTION
MATERIAL
THICKNESS
QTY
1
CUTTING EDGE
HB400
20mm
1
2
ROLL SHEET
ST52.3
6mm
1
3
SIDE TOP PLATE LH
HB400
10mm
1
4
SIDE TOP PLATE RH
HB400
10mm
1
5
SIDE BOTTOM-S30-LH
HB400
6mm
1
6
SIDE BOTTOM-S30-RH
HB400
6mm
1
7
TUBE
ST52.3
Ø73 x Ø59
1
8
TOP PLATE
ST52.3
10mm
1
9
FRONT GUSSET
ST52.3
12mm
2
10
SPILL GUARD
ST52.3
6mm
1
11
SPILL GUARD SUPPORT
ST52.3
6mm
2
12
BOTTOM WEAR STRIP-1
HB400
6mm
1
13
BOTTOM WEAR STRIP-2
HB400
6mm
1
14
BOTTOM WEAR STRIP-3
HB400
6mm
1
15
RH-EAR PLATE
ST 52.3
10mm
1
16
LH-EAR PLATE
ST 52.3
10mm
1
17
S30 PIN
EN8D
Ø30mm
2
18
EAR PLATE GUSSET
ST52.3
10mm
2
19
ATTACHMENT LLC LOGO
ST52.3
5mm
2
20
SUPPORT PLATE
ST52.3
6
1

NOTE:
STRUCK CAPACITY – 109 LITERS
HEAPED CAPACITY – 136 LITERS

Paint specification:
Bucket:RAL 9017 Traffic Black (Gloss Finish)
logo: RAL 5012 Light Blue (Gloss Finish)

diagram1 1
diagram3 1
diagram2 1
